Engine

Liquid-cooled, 4-Stroke Parallel Twin

Fuel System

Fuel injection: Ø 36 mm x 2 with dual throttle valves

Displacement

649 cm³

Ignition

Digital

Bore X Stroke

83 x 60 mm

Starting System

Electric Starter

Compression Ratio

10.8:1

Transmission

6-speed, return

Max Power

50.2 kW {68 PS} / 8,000 rpm

Max Torque

64.0 N•m {6.5 kgf•m} / 6,700 rpm

Final Drive

Sealed Chain

Lubricant System

Forced lubrication, Semi-Dry Sump

Front Suspension / Wheel Travel

Wheel Travel Ø41mm Telescopic Fork / 125mm

Front Brakes

Dual Semi Floating Ø300mm petal disc Caliper: Dual Piston

Rear Suspension / Wheel Travel

Horizontal Back-link with Adjustable Preload / 130mm

Rear Brakes

Single Ø220 mm petal disc. Caliper: Single-piston

Front Tyre

120/70ZR17M/C (58W)

Rear Tyre

160/60ZR17M/C (69W)

Frame Type

Trellis, high-tensile steel

Wheelbase

1,410 mm

Trail

100 mm

Seat Height

790 mm

Overall Height

1,145 mm

Fuel Capacity

15 litres

Overall Length

2,055 mm

Curb Weight

193 kg*

Overall Width

740 mm
